M/V VALLE DI NERVION 40,000 DWT OIL / CHEMICAL TANKER DOUBLE HULL SEGREGATED BALLAST |
|
TYPE OF VESSEL | |
IMO III oil product chemical carrier provided with double skin in way of cargo area and bunker tanks in E.R. space. Six pairs of cargo tanks (phenolic epoxy coated) and one pair of slop tank divided by one longitudinal bulkhead grouped in seven segregations. One recovery tank. |
|
BUILDER | |
Hyundai Mipo Dockyard Co., Ltd South Korea |
|
DELIVERY | |
2003 | |
MAIN CHARACTERISTICS | |
Length o.a. | 175.93 m |
Lenght b.p. | 169.62 m |
Breadth mld. | 31.00 m |
Depth mld. | 17.00 m |
Design draugh | 9.00 m |
Scantling draught | 9.00 m |
Corresponding deadweight | 40.218 metric tons |
PROPULSION PLANT | |
One supercharged diesel engine “HYUNDAI B&W 6S50MC”, two strokes, single acting connected with one fixed pitch propeller. Flap type rudder. |
|
Maximum Continuous Rating | 8,580 kW |
Speed | 15,00 knots |
Bow Thruster |
800 kW |
Engine Control Room for Unmanned Machinery Space 24/24 | |
CAPACITY (100% VOL.) | |
Cargo tanks including slop and recovery tank |
45,000 m3 |
Slop tank | 1,700 m3 |
Recovery tank | 370 m3 |
CLASSIFICATION & REGULATION | |
RINA STAR-HULL-NB; AUT-UMS; AUT-PORT; AUT-IMS; CLEAN-SEA; IV-INNATER SURVEY; CARGO CONTROL; MON-SHAFT; VCS; CLEAN-AIR; GREEN-STAR. SOLAS 74, AMENDMENTS UP TO 2000; MARPOL 1973/78 AND AMENDMENTS ANNEX I-II-IV-V-VI. COW, IGS, SBT, USCG, SUEZ, PANAMA, OCIMF. Bureau Veritas; AMS. EXXON Minimum Safety Criteria. |
|
GENERATING SETS | |
3×720 kW each diesel driven power generator burning HFO. 1×100 kW diesel driven emergency power generator. |
|
CARGO AND BALLAST SYSTEM | |
Six pairs of epoxy coated cargo tanks divided by corrugated transversal and centre line bulkhead and one pair of epoxy coated slop tanks grouped in seven segregations provided with double valve. All deck webs and longitudinals in way of cargo tanks above deck. Stainless steel cargo piping. Ten midship and two stern cargo manifolds. Stainless steel heating coils in cargo tanks to heat up cargo from 44°C to 96°C in 96 hours Midship and stern VECS (Vapour Emssion Control System). Indipendent oil fired IGS. Twelve submerged centrifugal hydraulic driven cargo pumps having capacity of 450 m3/h and total head of 120 mlc each for cargo tanks. Two submerged centrifugal hydraulic driven cargo pumps having capacity of 100 m3/h and total head of 120 mlc each for slop tanks. One submerged centrifugal hydraulic driven cargo pump having capacity of 70 m3/h and total head of 120 mlc for recovery tank. One Cargo Control Room provided with remote control of all cargo / ballast valves, remote level gauges (radar type), alarms and monitoring systems. |
|
CARGOES | |
Oil products, Pyrolitic Gasoline (Pygas), Xilene and mixtures, Toluene and mixtures, Benzene and mixtures, MTBE (Methil-Ter-Butyl-Ether), BTX (Benzene-Toluene-Xilene mixtures), IMO III products according to IBC code and type of cargo tank coating |
M/V VALLE DI GRANADA 35.000 DWT OIL / CHEMICAL TANKER DOUBLE HULL SEGREGATED BALLAST |
|
TYPE OF VESSEL | |
IMO III oil product chemical carrier provided with double skin in way of cargo area and bunker tanks in E.R. space. Six pairs of cargo tanks (phenolic epoxy coated) and one pair of slop tank divided by one longitudinal bulkhead grouped in seven segregations. One recovery tank. |
|
BUILDER | |
Hyundai Mipo Dockyard Co., Ltd South Korea |
|
DELIVERY | |
2005 | |
MAIN CHARACTERISTICS | |
Length o.a. | 175.93 m |
Lenght b.p. | 169.62 m |
Breadth mld. | 31.00 m |
Depth mld. | 17.00 m |
Design draugh | 9.00 m |
Scantling draught | 9.00 m |
Corresponding deadweight | 35.000 metric tons |
PROPULSION PLANT | |
One supercharged diesel engine “HYUNDAI B&W 6S50MC”, two strokes, single acting connected with one fixed pitch propeller. Flap type rudder. |
|
Maximum Continuous Rating | 8,580 kW |
Speed | 15,00 knots |
Bow Thruster |
800 kW |
Engine Control Room for Unmanned Machinery Space 24/24 | |
CAPACITY (100% VOL.) | |
Cargo tanks including slop and recovery tank |
45,000 m3 |
Slop tank | 1,700 m3 |
Recovery tank | 370 m3 |
CLASSIFICATION & REGULATION | |
RINA STAR-HULL-NB; AUT-UMS; AUT-PORT; AUT-IMS; CLEAN-SEA; IV-INNATER SURVEY; CARGO CONTROL; MON-SHAFT; VCS; CLEAN-AIR; GREEN-STAR. SOLAS 74, AMENDMENTS UP TO 2000; MARPOL 1973/78 AND AMENDMENTS ANNEX I-II-IV-V-VI. COW, IGS, SBT, USCG, SUEZ, PANAMA, OCIMF. Bureau Veritas; AMS. EXXON Minimum Safety Criteria. |
|
GENERATING SETS | |
3×720 kW each diesel driven power generator burning HFO. 1×100 kW diesel driven emergency power generator. |
|
CARGO AND BALLAST SYSTEM | |
Six pairs of epoxy coated cargo tanks divided by corrugated transversal and centre line bulkhead and one pair of epoxy coated slop tanks grouped in seven segregations provided with double valve. All deck webs and longitudinals in way of cargo tanks above deck. Stainless steel cargo piping. Ten midship and two stern cargo manifolds. Stainless steel heating coils in cargo tanks to heat up cargo from 44°C to 96°C in 96 hours Midship and stern VECS (Vapour Emssion Control System). Indipendent oil fired IGS. Twelve submerged centrifugal hydraulic driven cargo pumps having capacity of 450 m3/h and total head of 120 mlc each for cargo tanks. Two submerged centrifugal hydraulic driven cargo pumps having capacity of 100 m3/h and total head of 120 mlc each for slop tanks. One submerged centrifugal hydraulic driven cargo pump having capacity of 70 m3/h and total head of 120 mlc for recovery tank. One Cargo Control Room provided with remote control of all cargo / ballast valves, remote level gauges (radar type), alarms and monitoring systems. |
|
CARGOES | |
Oil products, Pyrolitic Gasoline (Pygas), Xilene and mixtures, Toluene and mixtures, Benzene and mixtures, MTBE (Methil-Ter-Butyl-Ether), BTX (Benzene-Toluene-Xilene mixtures), IMO III products according to IBC code and type of cargo tank coating |
M/V VALLE DI CORDOBA 35.000 DWT OIL / CHEMICAL TANKER DOUBLE HULL SEGREGATED BALLAST |
|
TYPE OF VESSEL | |
IMO III oil product chemical carrier provided with double skin in way of cargo area and bunker tanks in E.R. space. Six pairs of cargo tanks (phenolic epoxy coated) and one pair of slop tank divided by one longitudinal bulkhead grouped in seven segregations. One recovery tank. |
|
BUILDER | |
Hyundai Mipo Dockyard Co., Ltd South Korea |
|
DELIVERY | |
2005 | |
MAIN CHARACTERISTICS | |
Length o.a. | 175.93 m |
Lenght b.p. | 169.62 m |
Breadth mld. | 31.00 m |
Depth mld. | 17.00 m |
Design draugh | 9.00 m |
Scantling draught | 9.00 m |
Corresponding deadweight | 35.000 metric tons |
PROPULSION PLANT | |
One supercharged diesel engine “HYUNDAI B&W 6S50MC”, two strokes, single acting connected with one fixed pitch propeller. Flap type rudder. |
|
Maximum Continuous Rating | 8,580 kW |
Speed | 15,00 knots |
Bow Thruster |
800 kW |
Engine Control Room for Unmanned Machinery Space 24/24 | |
CAPACITY (100% VOL.) | |
Cargo tanks including slop and recovery tank |
45,000 m3 |
Slop tank | 1,700 m3 |
Recovery tank | 370 m3 |
CLASSIFICATION & REGULATION | |
RINA STAR-HULL-NB; AUT-UMS; AUT-PORT; AUT-IMS; CLEAN-SEA; IV-INNATER SURVEY; CARGO CONTROL; MON-SHAFT; VCS; CLEAN-AIR; GREEN-STAR. SOLAS 74, AMENDMENTS UP TO 2000; MARPOL 1973/78 AND AMENDMENTS ANNEX I-II-IV-V-VI. COW, IGS, SBT, USCG, SUEZ, PANAMA, OCIMF. Bureau Veritas; AMS. EXXON Minimum Safety Criteria. |
|
GENERATING SETS | |
3×720 kW each diesel driven power generator burning HFO. 1×100 kW diesel driven emergency power generator. |
|
CARGO AND BALLAST SYSTEM | |
Six pairs of epoxy coated cargo tanks divided by corrugated transversal and centre line bulkhead and one pair of epoxy coated slop tanks grouped in seven segregations provided with double valve. All deck webs and longitudinals in way of cargo tanks above deck. Stainless steel cargo piping. Ten midship and two stern cargo manifolds. Stainless steel heating coils in cargo tanks to heat up cargo from 44°C to 96°C in 96 hours Midship and stern VECS (Vapour Emssion Control System). Indipendent oil fired IGS. Twelve submerged centrifugal hydraulic driven cargo pumps having capacity of 450 m3/h and total head of 120 mlc each for cargo tanks. Two submerged centrifugal hydraulic driven cargo pumps having capacity of 100 m3/h and total head of 120 mlc each for slop tanks. One submerged centrifugal hydraulic driven cargo pump having capacity of 70 m3/h and total head of 120 mlc for recovery tank. One Cargo Control Room provided with remote control of all cargo / ballast valves, remote level gauges (radar type), alarms and monitoring systems. |
|
CARGOES | |
Oil products, Pyrolitic Gasoline (Pygas), Xilene and mixtures, Toluene and mixtures, Benzene and mixtures, MTBE (Methil-Ter-Butyl-Ether), BTX (Benzene-Toluene-Xilene mixtures), IMO III products according to IBC code and type of cargo tank coating |
